What is the maximum vehicle weight the 44030E can lift? ▾
The Challenger 44030E has a rated lifting capacity of 30,000 lb. This capacity rating applies to the total vehicle weight distributed across all four runways. Never exceed the rated capacity, and always ensure vehicles are properly centered on the lift before raising.
What is the difference between the 44030 and 44030E models? ▾
The 44030E is the extended-length version of the standard 44030. The 44030E offers a 290" maximum wheelbase compared to 230" on the standard model, with an overall length of 29' 7.5" versus 24' 7.5". Both models share the same 30,000 lb capacity, 68" rise height, and power requirements. Choose the 44030E for longer wheelbase vehicles like extended cab trucks or vehicles with rear-mounted equipment.
What electrical service is required for the 44030E? ▾
The 44030E requires 208-230V single-phase power at 30 amps. This is a significant advantage over larger capacity Challenger lifts (40K-60K) that require three-phase power. You'll need a dedicated 30-amp circuit with time-delay fuse or circuit breaker, and minimum 10-gauge wire (8-gauge preferred). A licensed electrician should verify your electrical service meets requirements before installation.
What are the concrete floor requirements? ▾
The floor must be a minimum of 4" thick reinforced concrete with steel rebar and a minimum compressive strength of 3,000 PSI. Concrete should be cured at least 28 days before installation. Anchor bolts must be positioned at least 5" from any slab edge or seam. Maximum floor variation between any two anchor points is 2 inches. Failure to meet these requirements could result in unsafe operation and void the warranty.
How much space do I need for the 44030E? ▾
The 44030E requires a minimum bay size of 15' 6" x 35' 0" for the lift footprint. You'll also need at least 16 feet of ceiling height (higher may be needed depending on vehicle height). Plan for additional clearance around the lift for vehicle approach, technician workspace, and safe operation of the approach ramps.
What warranty coverage does the 44030E include? ▾
Challenger provides a limited lifetime warranty on structural components (columns, runways, cross rails), 5-year warranty on hydraulic cylinders, 2-year warranty on the power unit and motor, and 1-year warranty on mechanical wear components like chains and locks. Warranty requires proper installation and maintenance per the manual. See the warranty document for complete terms.
What's included with the lift purchase? ▾
The 44030E ships complete with all structural components, power unit, hydraulic cylinder, chains, hardware, anchor bolts, and installation manual. You'll need to supply approximately 6 gallons of SAE-10 hydraulic oil, electrical wiring and installation, and compressed air for the pneumatic lock release. Professional installation labor and any concrete work are not included.
How long does it take to raise a vehicle? ▾
The 44030E has a rise time of approximately 105 seconds to reach the full 68" lift height. The 3 HP single-phase motor provides consistent lifting speed regardless of load weight up to the rated 30,000 lb capacity.
Are rolling jacks available for the 44030E? ▾
Yes, Challenger offers optional 15,000 lb capacity rolling air jacks (model WAJ15) for the 44030 series. These jacks allow you to lift individual axles for complete tire and brake service while the vehicle is on the 4-post lift. When using rolling jacks, the width between runways adjusts from the standard 54"-75" range.
Can I extend the runway length further? ▾
Yes, optional 3-foot track extension kits are available to increase the wheelbase capacity beyond the standard 290". Extensions can be installed at one or both ends of the lift. Challenger recommends installing extensions at the ramp end when using only one set. Contact us for extension kit pricing and availability.
What maintenance does the 44030E require? ▾
Regular maintenance includes checking all bolts and nuts for tightness, inspecting equalizer chains for proper tension, checking hydraulic lines and fittings for leaks, verifying lock operation, and inspecting the concrete floor for cracks near the base plates. During the first week after installation, check and tighten anchor bolts daily. See the operation manual for complete 30-day maintenance procedures.
How is the lift shipped and what do I need for delivery? ▾
The 44030E ships via freight truck on pallets from Louisville, Kentucky. Free shipping is included to commercial addresses in the 48 contiguous states. You'll need a forklift or loading dock to unload the shipment - liftgate service is available for an additional charge. Always inspect packages for damage before signing the Bill of Lading and note any damage on the delivery receipt.
