What is the maximum vehicle weight the Challenger 44050 can lift? ▾
The Challenger 44050 has a rated lifting capacity of 50,000 lb. This capacity accommodates most Class 7 and Class 8 commercial vehicles, waste trucks, transit buses, fire apparatus, and heavy construction vehicles. Always verify your vehicle's weight is within the lift's rated capacity before operation.
What is the maximum wheelbase the 44050 can accommodate? ▾
The Challenger 44050 accommodates vehicles with wheelbases up to 310". For longer wheelbase vehicles, consider the 44050E (370" wheelbase) or 44050X (430" wheelbase) extended models in the same product family.
What electrical power is required for the Challenger 44050? ▾
The 44050 requires 230-460V three-phase electrical service. At 230V, the lift draws 42 amps; at 460V, it draws 21 amps. A licensed electrician should install and verify the electrical supply meets all local codes and the manufacturer's requirements.
What are the concrete requirements for installation? ▾
The Challenger 44050 requires a minimum 4" thick reinforced concrete floor, free from cracks and seams, rated at 3,500+ PSI, and cured for at least 28 days. The concrete must support the combined weight of the lift structure and the maximum rated vehicle load.
What does the Challenger warranty cover on the 44050? ▾
Challenger provides a 5-year warranty on structural parts (columns, runways, cross beams, ramps, carriage), 1-year warranty on functional parts (power unit, cylinders, hoses, hydraulic components, cables, valves, controls), and 1-year labor coverage. The warranty requires online registration and proper installation per manufacturer specifications.
What is included with the Challenger 44050? ▾
The 44050 includes the complete 4-post lift assembly with black columns, 32" diamond-plate runways, approach ramps, 15HP power unit, dual lift cylinders, synchro-power controls, air actuated lock release system, hardware and anchor kit, and installation manual. Rolling jacks, electrical installation, concrete work, and installation labor are not included.
How is the Challenger 44050 shipped? ▾
The 44050 ships via freight truck with free shipping to commercial addresses in the 48 contiguous United States. Due to its size and weight, a forklift or loading dock is required for unloading. Curbside delivery is standard. Contact us for international shipping quotes.
Are rolling jacks available for the 44050? ▾
Yes, Challenger offers optional rolling jacks with capacities ranging from 15,000 lb to 35,000 lb specifically designed for use with the 44050 and similar heavy-duty 4-post lifts. These jacks allow technicians to raise individual axles for brake, suspension, and wheel service without repositioning the entire vehicle.
What is the difference between the 44050, 44050E, and 44050X models? ▾
All three models share the same 50,000 lb capacity but differ in maximum wheelbase accommodation: the 44050 handles up to 310", the 44050E extends to 370", and the 44050X reaches 430". Overall length increases accordingly: 36' for the 44050, 41' for the 44050E, and 46' for the 44050X. Choose based on the longest wheelbase vehicles you need to service.
What is the synchro-power system and why is it important? ▾
The synchro-power system features dual heavy-duty lift cylinders with lever controls that provide variable or synchronous power to the front and rear lift sections independently. This is essential for heavy vehicles with uneven weight distribution, such as waste trucks with heavy front-mounted hoppers or construction vehicles with rear-mounted equipment, allowing safe and level lifting regardless of load balance.
How long does it take to raise a vehicle to full height? ▾
The Challenger 44050 achieves full rise (73") in approximately 75 seconds when lifting at rated capacity. The 15HP three-phase motor provides consistent lifting speed to minimize vehicle positioning time and maximize shop productivity.
Is professional installation required? ▾
While not strictly required, professional installation is strongly recommended for heavy-duty lifts like the 44050. Proper installation by a qualified lift installer ensures safe operation and is necessary to validate the manufacturer warranty. Contact Garage Supply Guys for installer recommendations in your area.
