What does "Less Superstructure" (LS) mean? ▾
Less Superstructure means this listing includes the complete inground lift units (cassette tub, pistons, power unit, controls, and safety locks) without the superstructure assembly. The EV1020SS superstructure kit, which includes 3-stage front and rear arms, double telescoping screw pads, extensions, and frame engaging adapters, must be purchased separately for each lift unit to achieve a fully operational lift system.
Why would I order the LS model instead of the complete lift? ▾
The LS configuration is designed for facilities that are replacing lift mechanisms in existing pits where superstructure components are being retained, ordering superstructures separately to match specific service requirements, or phasing installation across multiple purchase orders. It allows flexible component sourcing while ensuring the core lift hardware is factory-matched.
How many lift units are included in this listing? ▾
This listing includes 2 complete EV1020-QC inground lift units. Each unit is a self-contained inground lift with its own Quick Cycle power unit, 8.5" chrome pistons, sealed polymer cassette tub, mechanical safety locks, and wall-mounted controls. Both units ship together for coordinated multi-bay installation.
What is Quick Cycle and how fast is it? ▾
Quick Cycle technology uses an upgraded pump (4cc vs the standard 2.5cc) to deliver a 27-second rise time and 17-second lowering time, compared to the standard EV1020's 38-second rise time. This represents over 40% faster operation, making Quick Cycle the preferred choice for high-volume service environments where faster lift transitions directly impact daily throughput.
What is the lifting capacity of each unit? ▾
Each EV1020 lift unit has a total lifting capacity of 10,000 lb with 2,500 lb capacity per arm. This accommodates passenger cars, crossovers, SUVs, and light trucks. The 8.5" chrome pistons provide greater stability under load compared to smaller-bore competitive designs.
What is the difference between the EV1020 and EV1220? ▾
The EV1020 has a 10,000 lb capacity with 2,500 lb per arm and a 97" overall width, while the EV1220 has a 12,000 lb capacity with 3,000 lb per arm and a 115" overall width. Both share the same 87" drive-thru clearance and 8.5" chrome pistons. The EV1020 offers a more compact footprint ideal for standard passenger vehicle service, while the EV1220 handles heavier commercial vehicles.
What electrical power does each lift require? ▾
Each EV1020-QC lift unit requires 208-230V, 60Hz, single phase power with a dedicated 2HP motor circuit and 30A service. Since this is a set of 2 lifts, your facility will need 2 separate electrical circuits meeting these specifications. A licensed electrician must install and verify electrical supply for each unit.
What superstructure do I need to complete the lift? ▾
Each lift unit requires one EV1020SS superstructure kit. The superstructure includes 3-stage front and rear arms with reach from 19.625" to 42.125", double telescoping screw pads adjustable from 3.875" to 6", standard and medium extensions, high extensions, and frame engaging truck adapters. Frame engaging adapters are required when lifting vehicles with frame construction.
Is compressed air required? ▾
Yes, each lift unit requires compressed air at 90-120 PSI for the mechanical lock release mechanism. Ensure your shop air system can provide adequate pressure and volume for consistent operation across both lifts, especially during simultaneous use in adjacent bays.
Is this lift ALI/ETL certified? ▾
Yes, the Challenger EV1020 carries both ALI (Automotive Lift Institute) and ETL certification, validating that the lift meets recognized safety and performance standards. This third-party certification provides documented compliance appropriate for professional service facilities and insurance requirements.
What warranty coverage is included? ▾
Challenger provides a 5-year warranty on structural components, 2-year warranty on functional parts (power units, cylinders, hoses, controls), and 1-year warranty on electrical components. An optional extended warranty adding 3 years of functional parts coverage is available within 30 days of purchase. Warranty registration must be completed within 30 days of installation.
What maintenance does this lift require? ▾
Challenger EV Series inground lifts require quarterly greasing of bearings, which is less frequent than competitive models that require monthly maintenance. Regular inspection of safety locks, hydraulic fluid levels, wipers, and piston condition should follow the maintenance schedule in the installation manual. The optional StayDry kit (SD100) automates condensate removal from the cassette tub.
